Low VSWR, high cost-effectiveness.
| Parameters | Min | Typical | Max | Units |
| Frequency | DC | ~ | 26.5 | GHz |
| IL | 0.2 | dB | ||
| VSWR | 1.15 |
| Impedance | 50Ω |
| Connector | SMA-K & SMA-K |
| Surface | Passivation of stainless steel |
| Product shell material | Stainless steel SUS303F |
| Inner conductor | Beryllium Copper Gold Plated |
| Spanning | PTFE |
| Work Temp. | -55~+125℃ Design assurance |
| F(GHz) | S21(L) | S22(V) |
| 0.01 | -0.01 | 1 |
| 1.51 | -0.02 | 1.01 |
| 3.01 | -0.03 | 1.04 |
| 4.51 | -0.03 | 1.03 |
| 6.01 | -0.05 | 1.02 |
| 7.51 | -0.06 | 1.05 |
| 9.01 | -0.07 | 1.05 |
| 10.51 | -0.08 | 1.07 |
| 12.01 | -0.08 | 1.1 |
| 13.51 | -0.08 | 1.08 |
| 15.01 | -0.07 | 1.06 |
| 16.51 | -0.08 | 1.09 |
| 18.01 | -0.09 | 1.13 |
| 19.51 | -0.09 | 1.1 |
| Type | Coaxial |
|---|---|
| Frequency | 26.5 GHz |
| Connector 1 type | SMA (f) |
| Connector 2 type | SMA (f) |
| VSWR (Max.) | 1.15 |
